Urban Cruzer Step Through
Product info
The Urban Cruzer is a strong, lightweight, sporty aluminum framed, 7-speed entry level electric bicycle built with high quality parts and mainstream components. It's economical, fast, silent, and fun to ride. Whether you're trekking down country roads, riding on light trails or commuting in the city, the Urban Cruzer will get you there in a flash. Built to last with warranty and service to match.
With a high load rating of 100kg and 500 watts of high climbing power, tackling hills has never been easier and you won't be late for work. Delicately balanced with a mid bike battery configuration to optimize handling, it provides a silent smooth ride with power and comfort. The Samsung cell Lithium-ion battery can be charged on the bike, or easily removed for storage or charging in your home, office, or on the go. Get to work faster without sweating on this zero emissions E-Bike.
The Urban Cruzer comes standard with a King Meter® Km LCD display, 5 speed pedal assist, walk mode, indicator, thumb throttle, molded hand grips, city tires, front head light, front/rear fenders, and rear carrier rack with tail and brake light. It's the most powerful, street legal, road bike with a 45 – 85 km (28 miles - 52 miles) range.
Tech Specs
- Motor
- Quiet, powerful, 8-Fun® 500W brushless rear hub motor, 48V DC
- Battery
- Samsung Cells, Lithium-ion 48V 13amp hour, centre rack mounted, removable battery pack with battery lock, easy access charger port
- Charging System
- Safe, Smart Charger® 120-240V with LED status display for lithium ion, C-UL-US approved for North America
- Charging Time
- 5-7 hours to 100%
- Frame
- Aircraft grade aluminum frame, mid-rise bar stem
- Forks
- Alloy Top Gun suspension with fender eyelets
- Seat Post
- Alloy, with shock absorber, Pro-Max Quick Release
- Seat
- Wide, Extra comfortable cushion saddle, spring loaded GS-808, 3-way adjustable
- Seat Height
- Minimum: 863mm (34 Inches) from the ground, 774mm (30.5 Inches) from the pedal
Maximum: 977mm (38.5 Inches) from the ground, 876mm (34.5 Inches) from the pedal
- Hand Grips
- Molded soft feel hand grips
- Pedals
- Full metal, light-weight
- Wheel Size
- 26" (66cm)
- Wheel Base
- 1200mm (47.3in)
- Tires
-
CST, Tracker, City Classic, All season 26”x1.75, debris inhibitor tread
- Rims
-
Heavy duty double walled MTX-300 alloy rims with eyelets, 66cm (26”)
- Spokes
-
Stainless Steel 12AWG rear
Stainless Steel 13AWG front
- Brake Calipers
-
Nutt JAK S-5 Series Dual Action Synchronous Low Brake Energy Loss
C/W Shimano compatible M515 to M575 rectangle high wear resistance brake pads
- Brake Handles
- Alloy linear pull with built-in motor inhibitor switches
- Rear Derailleur
-
Tourney Seven Index
Compatible with 7-speed SIS Index Shifting drivetrains
- Casette
- Shimano® Mega Range Freewheel, 7 Gear super low 14-34T cluster
- Controller
- 48V fully potted, with power gauge function
- User Controls
- Battery ignition key, King Meter® Km LCD display with 5 speed pass function, speed indicator, backlight, local time, top riding speed, motor power, riding distance, walk function (metric/imperial) battery gauge, thumb throttle, bike bell
- Speed Potential
- 32km (20mph)
- Range
-
45km to 90km (28 miles to 56 miles)
- Weight Capacity
- 100kg (220.5lbs)
- Product Size
- 185 x 62 x 100cm (972.8 x 24.4 x 39.4in)
- Total Bike Weight
- 27.5kg (60.3lbs)
* Technical Specifications are subject to change without notice.
